Ever since its establishment, NANLUX has been pushing the boundaries of technology and integrating it into products in order to bring users creative tools with higher efficiency and possibility. NANLUX is in constant communication with users within the industry to explore new possibilities for products. As an answer to the expectation of full color and powerful point source lighting, the Evoke 900C arrives. Equipped with RGBLAC color mixing system and Art-Net/sACN controls, the Evoke 900C is capable of delivering realistic lighting while fitting perfectly into virtual production.
Extraordinary Output and Flexibility
Full-color LED Spotlight
940W
Rated Power
12,940 lux@3m
With 45° Reflector / 5600K
As a point source LED, a quick switch between soft and hard light can be easily achieved on the Evoke 900C via attaching different modifiers. Flooding, spotting and cutting are also sure things in order to provide more light-shaping freedom for image making.
For virtual production, which has unlimited potential in the future of production, the Evoke 900C will make the presentation with more natural looks, create realistic and natural light, thus greatly improve shooting efficiency.
Blending Six Colors, Achieving New Heights
The Evoke 900C is adopted with the state-of-the-art RGBLAC six color mixing system. adding Lime, Amber and Cyan on the base of the primary colors RGB, reaching a new altitude in color accuracy.
Wider Color Space,
New Level Fidelity
CCT Range
1800K-20000K
CRI
Average 96
TM-30 Rf
Average 94
SSI
5600K:73
G/M Adjustment
G/M ±200
TLCI
Average 96
TM-30 Rg
Average 100
SSI
3200K:81
The RGBLAC color mixing technology on the Evoke 900C enables more color options,
and the ultra-wide CCT range also renders the accurate sunlight or moonlight while maintaining
excellent light quality all the time.
The G/M±200 of △uv adjusting range gives the Evoke 900C the ability of not only calibrating the G/M deviation, matching common light sources or other brands LED lights on the market, but also giving a more cinematic look to the frame.
Comprehensive Controls, Intuitive Operation
The Evoke 900C is built with a combination of 4 buttons, 3 knobs and an upgraded 3.5 inch full-color TFT screen, gives users an intuitive interface and a better operating experience. More comprehensive wired and wireless control methods are available for offering more flexibility for creators based upon the actual scenarios.

DMX/RDM    Wired Control Solution

The fixture comes with DMX 5-pin port, supporting DMX/RDM control and guaranteeing stable operation for large scenes.

Art-Net/sACN    Wired Control Solution

The Evoke 900C is equipped with 5-pin XLR in&out ports and LAN in&out ports, supporting basic DMX/RDM control and Ethernet control based on Art-Net/sACN protocol. Through the LAN ports’Art-Net/sACN control, the Evoke 900C could not only easily achieve a much longer distance of signal transmission than traditional cable plus a more convenient control across multiple universes, without affected by signal decay, but also embed seamlessly into Unreal Engine’s lighting system with the matching DMX mode, allowing the Evoke 900C to respond correctly to changes in the virtual environment in real time.

NANLINK APP   Wireless Control Solution

Access the NANLINK wireless control system through the built-in 2.4G/Bluetooth

modules to achieve a precise and professional lighting control experience with ease.

LumenRadio CRMX   Wireless Control Solution

Through the built-in LumenRadio TimoTwo module, Evoke 900C can receive or

transmit CRMX signal, and have the ability to cooperate with other lighting fixtures.

More Lighting Modes
The Evoke 900C incorporates more versatile lighting modes, which include CCT mode with G/M adjustment, Advanced HSI mode, RGBW mode, XY coordinates and GEL mode. And a DMX mode is developed specifically for virtual production under DMX control. The wide and complete selection of lighting modes gives users the key to adjust colors at will.
Advanced HSI mode:
Based on the original HSI mode and expand a higher level of customization, support free adjustment of the Intensity, Hue, Saturation and White Point Color Temperature.
RGBW Mode:
R/G/B/W channels can be controlled separately for more accurate color. *More than 1.84e+19 colors are accessible via DMX console.
XY Coordinates:
Precise color control through adjusting on the XY coordinates in the selected color gamut of CIE1931 color space.
GEL Mode:
Based on traditional gels, the gel mode provides a wide selection of 151 gels, saving time on the installation process and bringing a more convenient way in presenting the color and mood.

*Available to control on the NANLINK APP in the future
The Evoke 900C has 15 built-in effects to simulate the real lighting effects with all parameters adjustable via On-board, NANLINK APP, DMX and other control methods.
True Color · True Mirage
In today’s rapidly upgrading image-related technology, virtual production brings a new possibility by utilizing intelligent lighting systems, arc LED screen and virtual rendering system -- the corresponding perspectives and images in the virtual space can be presented through screen and lighting effects by capturing and computing the movement of the camera in real-time, so that the actors and crews can have a immersive feeling in action. As an intelligent lighting fixture, the Evoke 900C provides various lighting effects in the form of point source lighting with full color functionality. It achieves connections and integration at a higher level via a specially developed DMX mode and Ethernet control, combined with a virtual rendering system.
NANLUX have developed DMX mode -- RGB (NO DIMMER) specially to meet the demands from virtual production.By removing dimmer channel and adding Gamma responding option at the same time, lighting control for virtual production will become easier and more responsive. The Evoke 900C has the built-in Ethernet control upon Art-Net/sACN protocol for the first time, facilitating the integration into Unreal Engine’s lighting system, enabling fast and accurate respond to virtual environment changes in real time, enhancing the image expression with better detail.
Robust Structure, Weather Resistant
Evoke 900C retains the great features of the Evoke family for outstanding weatherproof performance -- IP55 rated for both the fixture and power supply, making it capable of withstanding extremely inclement weather conditions, the light is a trustworthy weapon for making astonishing images.
The tight and sturdy aluminum structure provides stability during operation. Convenience has been boosted in terms of installation, connection and adjustment.
Intelligent Fan, Handling Both Dissipation and Denoising
Evoke 900C incorporates a new generation adjustable fan control system with
SMART, FULL SPEED, LOW SPEED and OFF 4 modes, effortlessly meeting various
sound recording requirements.
Noise level is at 25 dBA under SMART mode.
Exceptional performance for both dissipation and noise control will surely bring
a better shooting experience for professional productions.
* Automatic switching fan speed under SMART mode by monitoring ambient temperature. Full power output under SMART mode; Full power output under FULL SPEED mode; Maximum power output is 70% under LOW SPEED mode; Maximum power output is 20% under OFF mode.
Maximum Modifiers, Maximum Shaping
The Evoke 900C continues with NL mount, supporting a seamless integration into NL mount ecosystem, takes various light shaping requirements into account with multiple modifiers.

Besides, the Evoke series are also compatible with other professional modifiers, such as DoPchoice. NANLUX always participates in the construction of professional lighting systems with a friendly and open attitude.
Includes

Evoke 900C ST-KIT
Evoke 900C × 1 Yoke × 1 Power Supply × 1 RF-NLM-45 Reflector × 1 DC Connection Cable 7.5M × 1 AC Power Cable 6M × 1 AS-CP-QR-EV Quick Release Clamp × 1 USB Flash Drive × 1 WS-RC-C2 Remote Controller × 1 User Manual × 1 CC-ST-EV900C Trolley Case × 1
Evoke 900C Flight Case Kit
Evoke 900C × 1 Yoke × 1 Power Supply × 1 RF-NLM-45 Reflector × 1 DC Connection Cable 7.5M × 1 AC Power Cable 6M × 1 AS-CP-QR-EV Quick Release Clamp × 1 USB Flash Drive × 1 WS-RC-C2 Remote Controller × 1 User Manual × 1 CC-EV1200-FT Flight Case × 1
Evoke 900C FL-YK-KIT Flight Case Kit
Evoke 900C × 1 Yoke × 1 Power Supply × 1 RF-NLM-45 Reflector × 1 DC Connection Cable 7.5M × 1 AC Power Cable 6M × 1 AS-CP-QR-EV Quick Release Clamp × 1 FL-35YK Lens × 1 USB Flash Drive × 1 WS-RC-C2 Remote Controller × 1 User Manual × 1 CC-EV1200-FL-YK-FT Flight Case × 1
